DD10
10 OUTPUTS

INPUT:18V2A
OUTPUT1-8:9V 500MA
OUTPUT9-10:18V500MA

SPECIFICATIONS

main body SIZE 120*70*25mm
main body WEIGHT 180g
PACKAGE SIZE 273 x 236 x 64 mm
PACKAGE WEIGHT 1266g
INPUT 18V2A
OUT POWER 27W（MAX）
OUT CHANNEL 10
OUTPUT 1-8 9V500mA
OUTPUT 9-10 18V 500mA
Short/overload
protection		 YES
ISOLATED FULLY ISOLATED



VIDEO
HIGHLIGHT
速卖通主图DD10.490
速卖通主图DD10.491
速卖通主图DD10.492
10 CHANNEL POWER SUPPLY COMPARISON

model DD10 AD10S-SV4
channel 10 10
input DC 18V AC 100V~240V
Wattage
 27W 55.4W
Includes 9V output 8 10
Adjustable voltage 0 4*  9V/12V/18V 450mA
18V OUT 2 4(adjustable)
size 120*70*25mm 195*88*35mm
weight 180g 605g

PACKING LIST
包装清单.395
1 x AC to DC Adapter 18V2A (negative polarity on the inside)
1 x Straight to Right-angled 30cm
10 x Straight to Right-angled 60cm
1 x Straight to Right-angled 90cm
1 x DC Voltage Doubler 2 Straight to 1 Straight male
1 x DC Current Doubler 2 Right-angled to 1 Straight male
1 x Battery clip on 9V battery Straight male  (negative polarity on the inside)
1 x Polarity conversion Right-angled male to Straight female 15cm
4 x HOOK& LOOP Straps
1 x Cable Locker Set
